Product code
400ER080
Manufacturer
Pro-Wave Electronic Corp.
The couple of transducer 400ET/R080 is suitable for outdoor low cost applications where the minimum measurable distance is a fundamental parameter or anyway for simple detection of people and objects passing.

The couple of transducer 400ET/R080 is suitable for outdoor low cost applications where the minimum measurable distance is a fundamental parameter or anyway for simple detection of people and objects passing.

Features

  • Work Environment: Indoor/ Outdoor
  • Configuration: transmitter (400ET080) and receiver (400ER080)
  • Working frequency: 40,0 ± 3KHz
  • Emitted sound pressure (to Fc, 0dB re 0.0002 μbar for 10Vrms to 30cm): 100dB min
  • Receive Sensitivity (Fc 0dB=1V/µbar): -80dBmin
  • Diameter: 8.4mm
Total angle at -6dB
125°
Dimension (mm)
8.4ø x 4.6
Working frequency
40.0 ± 1KHz
Function
Receiver
Housing
Aluminium
Type
Closed
Scheda tecnica221.2 KB
