TV80 0036
Product code
TV80 0036
Manufacturer
TV80 0036 interface board is compatible with all SONY HD block cameras.
FEATURES:
- SD and HDSDI Digital or analog HD and SD video output
- Simultaneous NTSC/PAL video output with 1080p60, 1080p30 or 1080p50, 1080p25 HDSDI format
- TTL or RS232 VISCA dialog level
- 6 to 12 VDC protected power supply for interface and camera
APPLICATIONS:
- Pharmaceutical
- Industrial
- Defence
- Medical imaging
Power Supply
6 a 12 VDC, 5 W (camera included)
Dimension (mm)
50 (H) x 50 (L) x 20 (P)
Output protocol
SDI & Analogue HD / SD
Working temperature
From 0°C to 60°C
Analogue Video Output
Simultaneous VBS NTSC/ PAL when configuration is HD 1080p60,1080p30 or 1080p50 1080p25
TV80 0036 Datasheet1.25 MB
TV80 0036 Technical Manual1.83 MB
