TV10 0070
Product code
TV10 0070
Manufacturer
LVDS to YPbPr, CVBS or HDMI interface board for TAMRON MP1010M-VC / MP1110M-VC
The TV10 0070 interface card is specifically designed for Tamron MP1010M-VC and MP1110M-VC camera block models with LVDS to HDMI or analogue HD/SD output.
FEATURES:
- Digital HDMI video output (up to 1080p60)
- CVBS & YC analog SD video output
- YPbPr analog HD video output (up to 1080p30)
- NTSC / PAL video format
- “Letter box” / “Crop” analog video conversion
- 720p50/60, 1080p25/30 (YPbPr)
- 1080p25/30 to PAL/NTSC (Y/C - CVBS)
- RS232 / TTL - VISCA serial control
- GPIO for zoom, focus, freeze control
- 8 to 12 VDC power supply
- Size : 55mm x 41.5mm
APPLICATIONS:
- Drones
- Video conference
- UAV's
- ROV's
- Inspection
- Traffic control
- ANPR
- Medical
Can be purchased together with accessory kit TV50 0015.
Power Supply
8-12 VDC 5W (including camera)
Video Output Standard Configuration
Micro switches
Connector
BNC, (SMB, MCX, OPTIONS)
Dimension (mm)
55 (H) x 41.5 (W) x 4.5 (D)
Output protocol
HDMI / YPbPr / CVBS
Regulation
EMC FCC part 15, PCB: UL 94 V0
Working temperature
From 0°C to 60°C
