TV10 0051

The board transmits and filters the signal from the 4K camera to provide an optimum quality of image.
All camera resolutions and frame rates are supported.

FEATURES:


• 2160p, 1080i, 1080p and 720p output support

• HDMI output 1.4b up to 49 ft. (15m)

• Internal Micro Coaxial Cable up to 400mm

• Board and Camera management via RS232/TTL

• Push buttons for zoom, freeze and  more (optional TV10 0022)

• Video format selection by micro switch

• Supply voltage: Power input 6 to 12V DC

• Tiny module size 63mm x 38mm x 7.5mm


APPLICATIONS:


• Medical, redefining imaging for surgey: thanks to the 4K technology, fine structures can be identified with greater precision, offering surgeons a clearer picture during open surgery or minimally invasive procedures

• Broadcast/sport: 4K picture gives the viewer at home the impression of actually being at the match and offers to the audience an immersive new experience

• CCTV industries, 4K surveillance with extra intelligence: One 4K monitor can display 4x4 scaled D1-size image which is very effective for viewing multiple cameras
