Ultra.Sens AK100
Product code
Ultra.Sens AK100
Manufacturer
The ULTRA.sens is the world’s first OEM gas measurement module based on miniaturized UV LEDs. The stability and lifetime of these UV-LEDs enables high-precision gas analyses down to the ppb range. By using two UV-LEDs 2 gases can be detected simultaneously. With this approach, 2 measuring ranges from ppm to Vol.-% can also be realized.
In the spectral range from 200 nm to 500 nm, nitrogen oxides (NO+NO2), aromatic hydrocarbons, hydrogen sulphide, ozone, sulphur dioxide and chlorine can be reliably detected with this novel sensor platform.
Applications:
- Environmental and Process Measurement Technology (CEM)
- Engine development
- TOC analyzers
- Elemental analysis
- Industrial gas analysis
- Natural gas/biogas analysis
- Process measurement technology
- Biogas research
- Measurement of SO2, NO2, NO, H2S, CL2, O3 in combination (3 gases) or as single gas module are possible
Accuracy
±2 % F.S.
Energetic consumption
< 3 Watt @ 24 VDC
Measurement range
< 1 Vol.%
Temperature range
5°C – 45°C
Target Gas
Multigas
Response Time
1 second (T90)
Output
RS232, Can, Analog
