EDI030305NG
Product code
EDI030305NG
Manufacturer
The Gascard NG is a OEM board with infrared sensor for the measuring of carbon monoxide.
This board, produced by Edinburgh Sensors, has beed developed to allow an easy integration in several applications in gas monitoring field and in particular for applications which need high quality, long term stability and precise measures. The board is temperature compensate and it has RS232 interface. As optional choice there is also the Ethernet interface.
The model EDI030305NG has range 0-3%.
Power Supply
24V DC (7-30V)
Measurement range
0-3%
Target Gas
Carbon Monoxide
Output
4-20 mA
0-20 mA
Scheda tecnica250.64 KB
