HCM1812

HCM1812
HCM1812
Product code
HCM1812
Manufacturer
JL World
Electroacustic Transducer, Electro-Magnetic and PIN mounting type

HCM1812 is a JL World electromagnetic buzzer, PIN mounting type.

Features:
Dimensions: 18x14x11 mm
Rated Voltage: 12 V
Operating Voltage: 6 ~ 15 V
Rated Frequency: 2048 Hz
Rated Current: <= 50 mA
SPL (sound pressure level) at 10cm: >= 85 dB

Coil Resistance (Ω)
120 ± 18
Rated Current (mA)
≤50
Rated Frequency (Hz)
2048
SPL at 10 cm (dB)
≥ 85
Technology
Electro-Magnetic
Operating temperature
-30 ~ +70
Operating Voltage (V)
6~15
Typology
Pin
HCM18 Datasheet194.11 KB
