H2 3E 1%

Measuring Range: 0–10000 ppm
Sensitivity Range: 10 nA/ppm ± 5 nA/ppm
Zero Current at 20°C: < ± 250 nA
Resolution at 20°C: < 20 ppm
Bias Potential: 0 V
Linearity: < 5% full scale

Response Time at 20°C:

• t50 < 40 s calculated from 2 min. exposure time
• t90 < 70 s calculated from 2 min. exposure time

Long Term Sensitivity Drift: < 10% per 6 months

Operation Conditions
Temperature Range: -20°C to +40°C
Humidity Range: 15–90% r.H., non–condensing

Effect of Humidity: no effect

Sensor Life Expectancy: > 24 months
Warranty: 18 months
