GS+4ETO
Product code
GS+4ETO
Manufacturer
Measurement Range 0 – 20 ppm
Output Signal 1900 ± 600 nA / ppm
Linearity: Linear
Repeatability < ±2% ETO equivalent
Response time, T90 <120 s
Maximum Overload 100 ppm
Long-term Output Drift <20% per annum
Recommended Load Resistor 10 ohms
Warranty 1 year from the date of dispatch
Resolution (Electronics dependent) 0.1 ppm typical
Life expectancy
> 2 years in air
Measurement range
0 - 20 ppm
Target Gas
Ethylene Oxide
Response Time
< 120 seconds (T90)
Output
1.9 ± 0.6 μA/ppm
Datasheet773.3 KB
GS+4ETO Recommended Circuit18.25 KB
